WindO/I-NV4 User’s Manual 35-1

MICRO/I Specifications

1.1 Packing content

Before installing the HG2J-7U, make sure that the model you have received is what you actually ordered, and no parts

are damaged to accidents during shipping.

1.2 Type No.

Chapter 35 MICRO/I Specifications

1 HG2J-7U

Name HG2J-7U

HG2J-7U Unit

Mounting clips

Communication plug for external devices (Attached to the HG2J-7U)

×1

×4

×1

LCD size Bezel color Type No.

7.0 inch wide TFT Color LCD Black HG2J-7UT22TF-B
