4 HG2G-5T, HG1G

35-56 WindO/I-NV4 User’s Manual

■ HG1G

*1 Operating temperature range will be -20 to +50 ° C if USB interface is used with 151 mA or more.

No. Name Description

(1) Display

(2) Touch Panel

(3) Power Supply Terminal Connector : Terminal Block 3-pin (Screw fastened type)

(4) Serial Interface (COM)

RS232C, RS422/485 Connector : Terminal Block 9-pin (Screw fastened type)

Maximum cable length: 15m (RS232C), 1,200m (RS422/RS485)

(5) Ethernet Interface (LAN)

IEEE802.3u 10BASE-T/100BASE-TX Connector : RJ-45

(With Auto MDI/MDI-X function)

Maximum cable length: 100m

(6) Battery Cover

(7) Mounting Clip Position 2 places

(8) USB Interface (USB1) USB2.0 (Device) Connector : Mini-B

(9) USB Interface (USB2)

USB2.0 (Host) Connector: Type A Output current : 5V 500mA

(1)

(2) (3) (7) (6) (8)(9)(5)

(4)

(7)
