Notes related to emissions

In order to meet the emission specifications for the HG2G-5T, HG1G, attach a ferrite core to the power cables and

communication cables.

Recommended ferrite core: ZCAT3035-1330 manufactured by TDK Corporation

Power supply

section

+- FE

Communication

section

External device

MICRO/I

DC power supply

Attach the ferrite core near the

power supply section of the power

cables connected to the MICRO/I

unit.

Attach the ferrite cores according to

the usage conditions of the external

devices, surrounding environment, and

the cables.
