WindO/I-NV4 User’s Manual 35-59
4 HG2G-5T, HG1G
35
MICRO/I Specifications
â– Performance Specifications
â– EMC Specifications
*3 Please be aware that small black and bright dots might show up on LCD Screen: it is not a failure or malfunction.
*4 The life of the LCD itself at an ambient temperature of 25°C. This is not a guaranteed value. The actual life depends on the
environment and conditions of use.
*5 It is a protection structure for the operating surface of HMI, which is attached to a panel. Although protection structure
suffices every test conditions, it does not guarantee to operate under all of the environmental condition.
As for IP65F/IP66F/IP67F oilproof structure, it suffices oilproof test conditions. Conditions are listed in the document that
comes with Japanese Industrial Standard JIS C 0920.
Protection structure do not gurantee usage under long exposure to oil or usage of oil that is not prescribed in the document.
Please test/check beforehand to avoid trouble.
Type No. HG2G-5TN HG2G-5TT HG1G
Display
LCD Type
*3
TFT Monochrome LCD
(TN Type)
TFT Color LCD (TN Type)
Display Colors 2 Colors (16 tones) 65536 Colors
Effective Display Area 115.2 (W) × 86.4 (H) mm 95.04 (W) × 53.856 (H) mm
Display Resolution 320 (W) × 240 (H) dots 480 (W) × 272 (H) dots
View angle
Left/Right: 65°,
Top: 80°, Bottom: 60°
Left/Right: 80°,
Top: 80°, Bottom: 80°
Left/Right: 70°,
Top: 60°, Bottom: 65°
Brightness of LCD only
1100 cd/m
2
500 cd/m
2
800 cd/m
2
Brightness Adjustment 32 levels
Backlight LED
Backlight Life
*4
Approx. 100,000 hours (The time until
brightness becomes 50% of the initial value)
Approx. 70,000 hours (The time until
brightness becomes 50% of the initial
value)
Touch
Panel
Switch Type Analog Resistive Film
Operating Force 3N maximum
Multiple Operations Impossible
Life 1,000,000 operations
User Memory Approx. 5 MB Approx. 12 MB
Backup Battery
Coin type lithium manganese dioxide battery CR2032
Guarantee Period: 1 Year (operating temperature at 25°C)
Recommended Replacement Span: Every 5 Years (operating temperature at 25°C)
Backup Data Calendar, Log Data, HMI Keep Relays, HMI Keep Registers
Buzzer output Single tone (tone length is adjustable)
Degree of Protection
*5
When panel thickness is 1 to 5 mm:
IP65F (IEC60529)
When panel thickness is 1.5 to 5 mm:
IP66F (IEC60529), TYPE 4X, TYPE 13
When panel thickness is 1 to 5 mm:
IP65F, IP67F (IEC60529)
When panel thickness is 1.5 to 5 mm:
IP66F, IP67F (IEC60529), TYPE
4X, TYPE 13
Weight (approx.) 500g 300g
Radiated Emission
Class A : 10m
40dBµV/m quasi-peak (30M to 230MHz)
47dBµV/m quasi-peak (230M to 1GHz)
Electrostatic Discharge
Contact : ±6kV
Air : ±8kV
Electromagnetic Field
10V/m (80M to 1.0GHz)
3V/m (1.4G to 2.0GHz)
1V/m (2.0G to 2.7GHz)
80% AM (1kHz)
Fast Transient Burst Power : ±2kV Communication cable : ±1kV
Surge Immunity ±500V (between +24V and 0V) ±1kV (between +24V and FE, 0V and FE)
Conducted Radio
Frequency Immunity
3V (Power, Communication cable) (150k to 80MHz)
80% AM (1kHz)
To Next Page
