5 HG1P

35-70 WindO/I-NV4 User’s Manual

5.1 Packing content

Before installing the HG1P, make sure that the model you have received is what you actually ordered, and no parts

are damaged to accidents during shipping.

5.2 Part Numbers

5 HG1P

Name HG1P

HG1P Unit

Instruction Sheet (Japanese/English) x1

Instruction Sheet (Chinese) x1

×1

Communication Interface Part No.

Serial Interface (RS422/485) HG1P-ST32YBFH-B0

Ethernet Interface HG1P-ST32ZBFH-B0
