WindO/I-NV4 User’s Manual 35-87

5 HG1P

MICRO/I Specifications

● Adjusting the Brightness

The brightness of the HG1P display can be adjusted on the Adjust Brightness Screen.

1 Press the [Adjust Brightness] at the bottom of the Maintenance Screen. The Adjust Brightness Screen appears.

2 Press the [<<] and [>>] at the bottom the Adjust Brightness Screen to adjust the brightness to the optimal setting.

3 Press the [X] to close the Adjust Brightness Screen.

Maintenance

System Mode

Device Monitor

Adjust Brightness

Maintenance

Adjust Brightness

To adjust the brightness in the System Mode, use the [<<] and [>>] buttons located at the bottom of the

Top Page.
