WindO/I-NV4 User’s Manual 35-89

6 Options

MICRO/I Specifications

6.1 Optional items

● HG2J-7U

*1 No UV resistant.

6 Options

Name Type No. Description

USB Panel-Mount Extension Cable HG9Z-XCE11

Extension cable for attaching to USB2 (Type-A) port on front

panel

Length: 1m

PLC Connection Cable

FC2A-KP1C

For IDEC FC4A/5A MICROSmart

Length: 2.4m

MICRO/I: Parted Wire

Host: Mini DIN 8-pin

HG9Z-XC275

For IDEC FC4A/5A MICROSmart

Length: 5m

MICRO/I: Parted Wire

Host: Mini DIN 8-pin

FC6A-KC1C

For IDEC FC6A MICROSmart

(FC6A-C*****E only)

Length: 5m

MICRO/I: Parted Wire

Host: RJ45

Protective Film

HG9Z-2D7PN05

For HG2J-7U

5 pcs/pack
