1 Creating and Manipulating WindO/I-NV4 Project Data

4-22 WindO/I-NV4 User’s Manual

4 Check the message and click Yes.

If there are no device addresses that correspond to the external device addresses used in the current

project data after changing the communication driver, the items set with those device addresses are blank.
