3 Project Settings Dialog Box
4-34 WindO/I-NV4 User’s Manual
System Area 4
This area reads the MICRO/I internal clock data in one minute intervals.
Address
number
Bit Function Description
+8
0 to 7 Clock data Month These bits store the current Month (01 to 12) value as a 2 digit BCD.
8 to 15 Clock data Year These bits store the current Year (00 to 99) value as a 2 digit BCD.
+9
0 to 7 Clock data Hour These bits store the current Hour (00 to 23) value as a 2 digit BCD.
8 to 15 Clock data Day These bits store the current Day (01 to 31) value as a 2 digit BCD.
+10
0 to 7 Reserved
8 to 15 Clock data Minute These bits store the current MICRO/I clock data Minute (00 to 59).
+11
0 to 3 Clock data Day of Week
These bits store the current Day of Week value as a 2 digit BCD. The
relationship between the day of the week and the value is as follows.
00: Sunday
01: Monday
02: Tuesday
03: Wednesday
04: Thursday
05: Friday
06: Saturday
4 to 15 Reserved
