WindO/I-NV4 User’s Manual 4-33
3 Project Settings Dialog Box
4
Project Settings
System Area 3
This area is for changing the MICRO/I internal clock data.
Address
number
Bit Function
Description
+3
0
Numerical input setting
complete
This bit changes to 1 when finished entering a numerical value with the
Numerical Input. This bit changes to 0 when entering a numerical value
or when entering a numerical value has been canceled. Write 1 to
numerical input setting clear (address number+1, bit 10) to clear this bit.
1
Numerical input setting
cancel
This bit changes to 1 when entering a numerical value with the Numerical
Input was canceled. This bit changes to 0 when entering a numerical
value or when entering a numerical value has been completed. Write 1 to
numerical input setting clear (address number+1, bit 10) to clear this bit.
2 Backlight auto off running
The value of this bit changes to 1 when Auto OFF is configured and the
backlight was turned off by this function. To configure Auto OFF, select
the Auto OFF check box under Backlight in the Project Settings
dialog box. This bit automatically changes to 0 when the backlight turns
on.
3
Sending output to a
printer
This bit changes to 1 when sending output to the printer. This bit
automatically changes to 0 when finished sending output.
4 Transferring recipe
This bit changes to 1 when transferring recipe data. This bit automatically
changes to 0 when the transfer is finished.
5
Character input setting
complete
This bit changes to 1 when finished entering text with the Character
Input. This bit changes to 0 when entering text or when entering text has
been canceled. Write 1 to character input setting clear (address
number+1, bit 11) to clear this bit.
6
Character input setting
cancel
This bit changes to 1 when entering text with the Character Input is
canceled. This bit changes to 0 when entering text or when entering text
has been completed. Write 1 to character input setting clear (address
number+1, bit 11) to clear this bit.
7 to 15 Reserved
Address
number
Bit Function Description
+4
0 to 7 Clock data Month Enter Month (01 to 12) as a 2 digit BCD.
8 to 15 Clock data Year Enter Year (00 to 99) as a 2 digit BCD.
+5
0 to 7 Clock data Hour Enter Hour (00 to 23) as a 2 digit BCD.
8 to 15 Clock data Day Enter Day (01 to 31) as a 2 digit BCD.
+6
0 to 7 Clock data Second Enter Second (00 to 59) as a 2 digit BCD.
8 to 15 Clock data Minute Enter Minute (00 to 59) as a 2 digit BCD.
+7
0 to 14 Reserved Enter 0 in the reserved area.
15 Update
Write 1 to this bit to write the entered data (address number+4 to
+6, bits 0 to 15) to the MICRO/I internal clock data.
When the value of the update bit (address number+7, bit 15) becomes 1, the clock data is updated as a
whole.
Year, month, day, hour, minute, and second cannot be set individually.
