WindO/I-NV4 User’s Manual 4-69
3 Project Settings Dialog Box
4
Project Settings
■ Inactivity Timeout
Set the timeout period between the MICRO/I and the FTP Client. After log in to the MICRO/I, if there is no
communication between the MICRO/I and the FTP client for a specified set time, the MICRO/I will automatically
disconnect the communication.
■ Specify Target
Select SD Memory Card
*1
, USB Flash Drive
*2
, USB1
*3
or USB2
*3
to specify target folder. When you specify the
target folder, you cannot access the higher level folders.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
*2 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
*3 HG2J-7U only
(Data Type): Select the data type for the timeout period until the MICRO/I disconnects the FTP client. Units are
minutes.
Value: Use a constant value (1 to 60).
Device Address: Use a value of device address.
Click to display the Tag Editor. For the device address configuration procedure,
refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
• The timeout period to login the MICRO/I is 1 minute.
• If Device Address is selected for (Data Type), note the following points:
- When the value of device address is 0, the Inactivity Timeout is 1 minute, and when the value of device
address is 61 or more, the Inactivity Timeout is regarded as 60 minutes.
- Once a network connection is established between the FTP client and the MICRO/I, the timeout period
cannot be changed. The timeout period needs to be set in Device Address before connecting the FTP
client to the MICRO/I.
Location: Specify the location of the target folder path. The maximum number is 247 characters. Only alphanumeric
characters and symbols can be used. Path delimiters and characters that cannot be used vary based on
the model.
Example: Access the “RECIPE” folder under “HGDATA01” folder on the external memory device
HG2J-7U: HGDATA01/RECIPE
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: HGDATA01\RECIPE
Model
HG2J-7U
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P
Delimiter Characters that cannot be used
" # $ & ' ( ) * : ; < > ? \ ` | ~
" * : ; < > ? |
/
\
To Next Page
