WindO/I-NV4 User’s Manual 5-21
4 Popup Screen
5
Screen
■ Title
Enter the Popup Screen’s title. Maximum number is 40 characters. This title is displayed in the Popup Screen’s title bar.
This option can only be entered when Use Text Manager is cleared.
■ Size
■ Screen List
This list shows screens that have already been created. It is only displayed when creating a new screen.
●
Options Tab
■ Background Color
Select the screen’s background color (color: 256 colors, monochrome: 16 shades). Click this button to open the color
palette. Select the color with the color palette.
■ Screen Effects
Width, Height: Specify the width (40 dots to Base Screen width) and the height (40 dots to Base Screen height) of
the Popup Screen.
None: Displays the Popup Screen’s background with the color specified in Background Color.
Transparency: Displays the Popup Screen’s background as transparent. The amount of transparency can be selected
from 10% to 90% in 10% increments.
Superimpose: Displays the Popup Screen’s background as completely transparent. The screen underneath the
Popup Screen can be seen.
For the Popup Screen set to Superimpose as Screen Effects, note the following points:
• Magenta (R:255, G:4, B:255) is treated as a transparent color. If you place pictures on the Popup Screen
set to superimpose that use this color, those areas are completely transparent.
• The buttons underneath the Popup Screen are active.
• When you place the following objects, the text is displayed with a color mixed with magenta. If the text
color causes a problem, set the Background Color of the text or change it to a Windows font.
- Text with Background Color set to None
- Parts with Image Type set to None
- Parts for which Not Display Image is selected
- Parts using the pictures with the background of the texts replaced with a Transparent Color
To Next Page
