3 Goto Screen Button

8-44 WindO/I-NV4 User’s Manual

Configure Processing Area of User Account Setting Screen Dialog Box

■ Top Device Address

Specifies a word device to use Processing Area of User Account Setting Screen. This option uses 152 words of address

numbers starting from the address number of the specified device address. You can only specify an internal device.

Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device

Address Settings” on page 2-70.
