WindO/I-NV4 User’s Manual 8-77
5 Key Button
8
Buttons
Upload Project is selected.
*1 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
*2 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
*3 HG2J-7U only
Destination: Displays a download destination of the project.
Clear Keep Devices:
Select this check box to clear keep devices after the project data is downloaded. However,
when project data that changes the system software or settings of the data storage area is
downloaded, the keep devices are always cleared.
When project data is downloaded, the alarm log data, data log data, and operation log data is deleted
regardless of the state of the Clear Keep Devices check box.
Starts running without displaying the Result window:
Select this check box to start running MICRO/I without displaying the execution result
screen after the project data is downloaded.
Destination: Specify where to save the project uploaded from MICRO/I. Select the location:
SD Memory Card
*1
, USB Flash Drive
*2
, USB1
*3
or USB2
*3
.
Location: Specify the location where the uploaded project will be saved. The maximum number is 247
characters. Only alphanumeric characters and symbols can be used. Path delimiters and
characters that cannot be used vary based on the model.
Example: To save project to the folder “Uploaded_Project” in an external memory device:
Uploaded_Project
Model
HG2J-7U
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P
Delimiter Characters that cannot be used
" # $ & ' ( ) * : ; < > ? \ ` | ~
" * : ; < > ? |
/
\
A uploaded project using the Data Transfer function is saved as a ZNV Project File(.znv).
