1 Pilot Lamp
9-8 WindO/I-NV4 User’s Manual
■ Align Text Vertical
Selects text alignment in the vertical direction.
Top, Center, Bottom
This option can only be configured when Left, Center, or Right is selected for Align Text Horizontal. If Center-
Left is selected for Align Text Horizontal, Center-Top is set as this option.
For details, refer to Appendix “5 Text Alignment” on page A-7.
■ Set by State
Select this check box if displaying different text when ON and OFF.
■ Use Text Manager
Select this check box if using the text registered in Text Manager for text display.
■ OFF, ON
Text: Inputs characters to be displayed on parts. The maximum number is 3,750 characters.
The characters that can be entered depend on the font selected using Font. For details, refer to
Chapter 2 “1.2 Available Text” on page 2-6.
Text ID: Specifies the Text Manager ID No. (1 to 32000) when using the text registered in the Text Manager.
Click to display Text Manager.
Can only be set when the Use Text Manager check box is selected.
Text Color: Selects the color of the text displayed on the part (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
Windows Font: Sets the font to be used as the Windows Font.
Select Windows using Font to display the current setting. You can specify the character spacing (0
to 100) and the line spacing (0 to 100). To change the settings other than the character spacing and
line spacing, click Change to display the Font Settings dialog box.
Can only be set when the Use Text Manager check box is cleared.
For details, refer to Chapter 2 “Windows Font” on page 2-13.
