8 Alarm Log Display

10-158 WindO/I-NV4 User’s Manual

■ (Show items detailed settings)

Each of the show items selected by the check boxes under Show Items can be configured in detail here.

■ Title

Select this check box to use text registered in Text Manager for Title in the (Show items detailed settings). The

Text ID message configured for Occurrence Time, Message, Recovery Time, and Confirmation Time is

displayed in (Show Items detailed settings).

Title: Double click the cell, and then enter the titles for the items to display. The maximum number is

100 characters.

Width: Specifies the number of characters to display (0 to 40). 1 is the width of a single-byte character,

2 is the width of a double-byte character.

Date: Selects the display type of the date from the following.

YY/MM/DD, MM/DD/YY, DD/MM/YY, MM/DD, DD/MM, non-display

Time: Selects the display type of the time from the following.

HH:MM, HH:MM:SS, non-display

• If the characters displayed in the title contain a newline, the text after the newline will not be displayed.

However, if using a Windows font for the selected text ID, the text after the newline will still be

displayed.

• If the title contains a language not supported as standard by the computer operating system, the

characters may be garbled when displaying the (Show items detailed settings). However, the

downloaded data is correctly displayed.

• If you change the display format for Date or Time, the number for Width is automatically adjusted.

• The text color for Message changes according to the alarm state. The text color for Message is

configured by Occurred Color, Recovered Color, and Confirmed Color on the Format tab.

Text ID: Specifies the Text Manager ID number (1 to 32000) when using text registered in Text Manager.

Click to display Text Manager.

This option can only be configured when the Use Text Manager check box is selected.
