WindO/I-NV4 User’s Manual 10-165
8 Alarm Log Display
10
Data Displays
Edit Dialog Box
Edit the settings for text color, background color, and flashing according to the status of alarm occurrence, recovery,
and confirmation of the selected level.
â–  Level
Displays the selected level in the (Color setting list by level and status) on the Format tab.
â–  Display
Select this check box to display the alarm at the level displayed in the Level on the Alarm Log Display.
â–  Occurred, Recovered, Confirmed
Edit the settings for text color, background color, and flashing according to the status of alarm occurrence, recovery,
and confirmation.
Text Color: Selects the text color of alarms (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
Background Color: Selects the Background color of alarms (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
Flash: Selects whether or not to flash alarms.
Flash intervals are set in the Flashing Cycle on the System tab in the Project Settings dialog
box.
