■ Data
Configures the details of the Data Log data.
Specify Size:
Specifies the height of rows in dots.
Enter the height (8 to (base screen vertical size -3)). The range that can be specified varies
based on the vertical size of the base screen and the character height.
The character height setting varies based on the model.
HG2J-7U: Size is 16.
To display a one-line message, 1 x 24 = 24 dots, a height of rows of 24 dots or higher is
required.
To display a two-line message, 2 x 24 = 48 dots, a height of rows of 48 dots or higher is
required.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: Magnification H is 1.
To display a one-line message, 1 x 16 = 16 dots, a height of rows of 16 dots or higher is
required.
To display a two-line message, 2 x 16 = 32 dots, a height of rows of 32 dots or higher is
required.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: Magnification H is 2.
To display a one-line message, 1 x 32 = 32 dots, a height of rows of 32 dots or higher is
required.
To display a two-line message, 2 x 32 = 64 dots, a height of rows of 64 dots or higher is
required.
24 dots
Height of Rows
LDR100 value
Data001
24 dots
48 dots
LDR100 value
Data001
LDR100 value
When the label is 2 lines,
2nd line is not shown.
Height of Rows Height of Rows
16 dots
Height of Rows
LDR100 value
Data001
16 dots
32 dots
LDR100 value
Data001
LDR100 value
Height of Rows Height of Rows
When the label is 2 lines,
2nd line is not shown.
Height of Rows
32 dots
LDR100 value
Data001
Height of Rows
32 dots
Height of Rows
64 dots
LDR100 value
Data001
LDR100 value
When the label is 2 lines,
2nd line is not shown.
Color: Selects the color for the displayed text (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
Align Text: Selects text alignment in the horizontal direction.
Left, Center, Right
For details, refer to Appendix “5 Text Alignment” on page A-7.
