WindO/I-NV4 User’s Manual 10-179
9 Data Log Display
10
Data Displays
■ Label
Configures the details of the label row.
Color: Selects the color for the displayed text (color: 256 colors, monochrome: 16 shades).
Click Color to display the Color Palette. Select a color from the Color Palette.
Align Text: Selects text alignment in the horizontal direction.
Left, Center, Right
For details, refer to Appendix “5 Text Alignment” on page A-7.
Height of Rows: Selects the specification method for height of the label row and configures the height of row.
Specify Number of Rows:
Specifies the number of rows. The range that can be specified varies based on the vertical size
of the base screen and the character height. When you enter the number of lines, the height of
rows is automatically calculated according to the display area.
Number of lines X Character height = Height of rows (dots)
The character height setting varies based on the model.
HG2J-7U: Size
Size is 16.
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: Magnification H x 16
Number of Lines Character Height Height of Rows
116× = 16 dots
LDR100 value
LDR100 value
Data001
216×=
LDR100 value
Data001
316×=
Number of Lines Character Height Height of Rows
Number of Lines Character Height Height of Rows
32 dots
48 dots
When the label is 2 lines,
2nd line is not shown.
Number of Lines Magnification H Height of Rows
11× × 16 = 16 dots
21××16=
31××16=
Number of Lines Magnification H Height of Rows
Number of Lines Magnification H Height of Rows
32 dots
48 dots
LDR100 value
LDR100 value
Data001
LDR100 value
Data001
32××16=
LDR100 value
Data001
Number of Lines Magnification H Height of Rows
96 dots
When the
l
abel is 2 lines,
2nd line is not shown.
Since the height of row is adjusted with the fixed number of the label rows, this option is convenient to use
when displaying multi-line labels.
