3 Configuration & Functions
2-52 WindO/I-NV4 User’s Manual
● View
View is where you can switch the workspace display and display the Tag Editor, Screen Diagram, and various
managers.
You can configure the items displayed in the editing window.
■ Workspace
■ Show/Hide
Command Description
Project Window
Shows the Project window. This window displays the saved screens and project
related information.
Screen List
Shows the Screen List window. The window displays the screens saved in the
project as thumbnails.
Object List
Shows the Object List window. This window displays all of the graphics and parts
placed in an editing screen.
Part Library
Shows the Part Library window. The part designs are listed in a window. You can
select a design from the displayed list and drag and drop it from the library screen to
the edit screen to create a screen. You can also register drawings, parts, and
grouped parts on the editing screen.
Tag Editor
Shows the Tag Editor. This window displays the list of registered device address, tag
name, and comments.
Comparison Result
Shows the Comparison Result window. This window displays the results of that
comparison of projects.
Screen Diagram
Shows the Screen Diagram. This window displays the Overlapping Screen
information, and the screen numbers and titles of the screens linked by the Goto
Screen Button, the Goto Screen Command, the Numerical Input, the Character
Input, the Alarm List Display and the Alarm Log Display.
Toolbox Shows the Toolbox window. This window displays Parts and Drawings.
Information
Shows the Information window. This window displays various information such as
error message.
Command Description
Part Name Shows or hides drawing object names and part names.
Device Address Shows or hides device addresses and tag names.
Trigger Condition Shows or hides trigger conditions.
Security Group
Display Shows or hides the display security group set for parts.
Input Shows or hides the input security group set for parts.
Top Layer Shows or hides drawing objects and parts placed on the top layer.
Popup Screen
Shows or hides a Popup Screen’s number, display frame, and the part name of the
part calling that Popup Screen.
Overlay Screens Shows or hides the configured overlay screens.
Commands Shows or hides the dotted frame for commands.
Gridlines Shows or hides the gridlines in the editing window.
