WindO/I-NV4 User’s Manual 11-25

2 Line Chart

Charts

■ Restart Chart

Select this check box to display the chart from the beginning when switching screens.

This option can only be configured when Log Trend (Normal) or Log Trend (Pen Recorder) is selected for Chart

Type.

MICRO/I MICRO/I MICRO/I

1234

100

-20

100

-20

Switch screen Switch screen

Base screen 1 Base screen 1Base screen 2

Display chart

from beginning
