• Output Alarm Log data to the external memory device

• Output Alarm Log data to the printer

*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F,

USB flash drive for HG2G-5T and HG1G/1P

Output to

External memory device

Alarm Log data (CSV)

External Memory Device

MICRO/I

USB flash drive

SD memory card

Output to printer

Printer

MICRO/I

HG3G

HG2G-5F

HG4G

HG5G-V HG4G-V HG3G-V HG2G-V

For compatible printers and instructions on how to connect one to the MICRO/I, refer to Chapter 32 “1.2

Connecting a Printer to MICRO/I” on page 32-1.
