138 Virtual Channels
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
4.7.1.3 P8
Pressure module P8
The pressure module has 8 physical channels.
The additional functions "Barometer" and "Status word" are available to this module under the function
group heading "Pressure". See below in the functions' reference for descriptions of these functions.
For sample applications, refer to the material on the isolated amplifier module.
4.7.1.4 UNI8
Universal amplifier module UNI8
The universal amplifier module has 8 physical channels. Along with the red-green LED, it has 2 additional
yellow LEDs, like the bridge amplifier does. These LEDs can be used for displaying module status
information. For details, refer to the material on the bridge amplifier module.
The additional functions "Channel-status word", "Module-status word", "button status", "Status auf LED"
and "short circuit status" are available to this module under the function group heading "Universal
amplifier". See below in the functions' reference for descriptions of these functions.
For sample applications, refer to the material on the isolated amplifier module.
4.7.1.5 DI16
Digital acquisition module DI16
This module has 16 digital inputs.
The additional functions "Event counting", "Frequency determination", and "Time determination" are
available to this module under the group heading "Pulse signals". See below in the functions' reference
for descriptions of these functions.
Sample application: A digital input bit is to be inverted and the results are to be transmitted by CAN-bus.
To do this, a virtual channel must be created and positioned in a CAN-message (using Drag & Drop). In
the settings dialog for this virtual channel, the function "Logical NOT" can be selected and its parameters
set.
