6.20 UNI8: universal
Variety
Properties
Remarks
ITT-VEAM
voltage measurements
voltage measurements with adjustable supply
current measurement
thermocouples
thermocouples, isolated*
temperature sensor Pt100
bridge-sensor
bridge: strain gauge
LEMOSA
DSUB 15
ZF LEMO
voltage measurements
voltage measurements with adjustable supply
current measurement (differential)
thermocouples
thermocouples, isolated*
temperature sensor Pt100
bridge-sensor (no ¼ bridge)
bridge: strain gauge
In this model, the contacts labeled G
and E in the circuit diagram are
committed. Thus, the following
functions are no longer available:
sensor recognition
¼ bridge completion and measurement
thermocouples with Pt100 in connector
3-wire Pt100 measurement
single ended current measurement
sensors with current signal
*the thermocouple has no low-impedance connection to the device ground.
Technical data UNI8.
CANSAS-L-UNI8 ITT-VEAM Signalseite
CANSAS-L-UNI8 ITT-VEAM CAN-Anschluss
