530 Pin configuration and power supply
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
8.1.3.2 Cables for µ-CANSAS
For connecting your imc µ-CANSAS modules, pre-configured cables are available. The connection
schematics below are to help you select the necessary components. Like the imc µ-CANSAS modules, the
imc µ-CANSAS cables are designed for use in extreme temperature conditions.
Pin configuration for signal inputs, see here .
µ-CANSAS connecting a single module
µ-CANSAS connecting 1-channel modules via a hub
µ-CANSAS connecting 4-channel modules in series
