168 Virtual Channels
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
4.10.47 Monoflop
Channel on which to perform the function.
Duration of the output pulse as a multiple of samples; range: 1 ... 65535
Digital channel containing the evaluated pulses
Description: The monoflop outputs an impulse in response to signal value transitions from zero to
nonzero. The return value is 1 during the impulse duration, otherwise 0. If the monoflop is not re-
triggerable, the zero-to-nonzero transition is only detected after an existing impulse is completed. If it is
retriggerable, the transition detection is always active and the response to a new transition to nonzero is
a new impulse which accordingly prolongs the existing impulse.
Data types:
