7.9 DO16
Datasheet Version 1.6 (16 digital outputs)
Parameter
Value (typ./max.)
Remarks
Channels
16 (2 x 8)
Each 8-channel-group isolated to the other
group as well as to power supply and CAN-bus.
No isolation within bank.
Separate voltage supply for each bank of 8
channels
Configuration options
Open-Drain
Totem-Pole
configurable independently for each 8-bit
channel group
Max. output level
5 V
max. 30 V
internal supply
external supply
Output current
High-level: 15 mA to 20 mA
Low-level: 700 mA
Low-level: <0.4 V
Power-up default
High-impedance
High
configured as Open-Drain
configured as Totem-Pole
Switching time
100 µs
CAN-Bus
defined according to ISO 11898
Isolation:
CAN-Bus
Power supply input
Digital outputs
60 V
60 V
60 V
to CHASSIS
nominal; testing: 300 V (10 s)
nominal; testing: 300 V (10 s)
nominal; testing: 300 V (10 s)
Externally available power
supply
5 V/ 30 mA per connector
available in addition to the output stages
Supply voltages
10 V to 50 V DC
Power consumption
4 W (typ.)
12 V supply, 23 °C
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
35 x 111 x 145 mm
41 x 128 x 145 mm
38 x 112.5 x 152 mm
CANSAS-DO16
CANSAS-L-DO16
CANSAS-K-D016 (8HP)
CANSAS-SL-DO16-D
Weight
300 g
Connection terminals
2x DSUB-15
PHOENIX spring cage terminal
block
2x DSUB-9
PHOENIX (MC 1,5/4STF-3,81)
CANSAS(-L)-DO16 outputs
CANSAS-K-DO16 outputs
CAN (in/out)
Supply
Connection terminals at SL
2x DSUB-15
2x 10-pin LEMO (HGA.1B.310)
1x 6-pin LEMO (HGA.1B.306)
outputs
CAN (in/out), supply (alternatively)
Supply
Module description DO16
