7.29.2 CAN-bus accessories
CAN-bus connection
cable with built-in
terminators
2 m long 1:1 cable; one side with 9-pin DSUB-socket,
one side with corresponding plug, built-in CAN-bus
terminators for connecting imc CANSAS to the
configuration interface in the PC
2 m long 1:1 cable; one side with 9-pin DSUB-socket,
one side with corresponding plug
2 CAN-bus terminators, cable; one with 9-pin DSUB-
socket, one with corresponding plug
imc CANSAS configuration plug with 9-pin DSUBsocket;
terminator not included, therefore only used in
conjunction with CAN/CABLE-TERMI!
Cables for imc CANSAS-IP65-P8
Adapter kit for
configuration
Terminal adapter-kit for configuration of a imc CANSAS-
IP65-P8 unit. Consists of cable set with 3-pin Amphenol
plug for imc CANSAS Power socket, 4-pin Amphenol, Y-
adapter with DSUB-plug and 9-pin sockets. DSUB-9 plug
terminated with Reset
Adapter for CAN
connection
Terminal adapter for imc CANSAS-IP65-P8 (4-pin
Amphenol plug for DSUB-9 terminal) for connection to
CAN/Y-cable
4-pin Amphenol to 4-pin Amphenol (female-female)
connection cable for pressure expansion
7.29.3 CANSAS power supply accessories
Power supply unit: input 240VAC, output 15VDC with
mains cable and Phoenix-plug for imc CANSAS POWER-
socket;
Supplies one imc CANSAS unit!
Input 110VAC, output 15VDC with mains cable and
adapter for imc CANSAS POWER-jack for the supply
of one imc CANSAS-module.
Connection plug for imc
CANSAS POWER-socket
4-pin Phoenix-plug and cover for connecting to imc
CANSAS POWER-socket
Cables for imc CANSAS-IP65-P8
Adapter for current
supply
Terminal adapter for imc CANSAS-IP65-P8 (3-pin
Amphenol plug for imc CANSAS Power socket) for
connection to the current supply for imc CANSAS CAN/
Power Supply Unit-230
Supply cable for pressure expansion
3-pin Amphenol to 3-pin Amphenol (female-female)
