6.10.2 Starting the DO8R, DO16R module
The relay's switching state is ON upon activating the DO8R-, DO16R-module. If a power-up value other
than 0 (zero) is set on the CAN-board, it only comes into effect after the module has been activated. To
boot the module typically takes < 1s.
Recommendation
If the software sets the value "0" as the rest state, the relays don't switch over after the system boots.
If the user wishes "1" to be the rest state, we recommend that the relay's ON and OFF be connected
the opposite way around, rather than setting the value by software.
6.10.3 Connector plugs DO8R, DO16R
CAN/DSUB-STD (Relais) is recommended and delivered per default. ACC/DSUB-REL4 can be used as
replacement with swapped pinning for ON and OFF. For the pin assignment of the DSUB-15 plugs see
here .
Pin configuration of imc CANSAS-L-DO8R-Ph with Phoenix terminal blocks .
Pin configuration of imc CANSAS-L-DO8R-V with ITT-VEAM terminals.
