Data types:
Input channel
Result channel
Integer
Digital
Unsigned Integer
Digital
4.10.25 Fixed analog value (only for DAC8 and PWM8 modules)
Parameter
Definition
Value
Fixed analog value, -10V ... +10V.
Result channel
Channel with constant (fixed) analog value
Description: Creates a channel with a fixed (constant) value. The value can be set to between -10V and
+10V.
Data types:
Result channel
Integer
4.10.26 Fixed digital value (only for digital output modules)
Parameter
Definition
Digital value
Constant (fixed) digital value, either 0 (FALSE) or 1 (TRUE).
Result channel
Channel with constant (fixed) digital value
Description: Creates a channel with a fixed (constant) value. The value can be set to either 0 (FALSE) or to
1 (TRUE).
Data types:
Result channel
Digital
4.10.27 Fixed input range
Parameter
Definition
Input channel
Channel to be re-scaled
Minimum
New lower limit of the value range
Maximum
New upper limit of the value range
Result channel
Re-scaled input channel
Description: The value range of a channel is re-scaled according to the user's specifications. The new
range is defined by a new lower range limit (minimum) and a new upper range limit (maximum). All the
input channel's sample values are linearly transformed to the result channel's new value range.
