6.17 PWM8 pulse width modulation outputs
8 digital outputs
Parameter
Value (typ./max.)
Remarks
Channels
8
Separate voltage supply for the two channel
groups.
The 4 outputs in a connector are isolated
from the outputs of other connectors, from
the supply and from the CAN-bus, but not
channel-to-channel.
Technical data PWM8.
6.17.1 8 PWM outputs
For purpose of using pulse width modulation as a control signal, the PWM (pulse width modulation) is
used. For the output, you can choose between TTL and an external voltage source (Open Drain).
The frequency is fix and can be be set individually for each channel:
Each 4-channel group in a connector is isolated from the other connector's channels and from the power
supply and CAN-bus.
