SENT: Gateway from SENT to the CAN-Bus 407
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
6.19.9 Pin configuration
DSUB-15 plug (female) IN 1..4 for inputs 1..4 and IN 5..8 for inputs 5..8.
Pin
plug (female) IN 1..4
plug (female) IN 5..8
1
imc internal use, service departure not for common use.
2
V Supply (5 V) Input 1
V Supply (5 V) Input 5
3
SIG Signal Input 2
SIG Signal Input 6
4
GND Input 2
GND Input 6
5
V Supply (5 V) Input 3
V Supply (5 V) Input 7
6
SIG Signal Input 4
SIG Signal Input 8
7
GND Input 4
GND Input 8
8
Not used
Not used
9
SIG Signal Input 1
SIG Signal Input 5
10
GND Input 1
GND Input 5
11
V Supply (5 V) Input 2
V Supply (5 V) Input 6
12
SIG Signal Input 3
SIG Signal Input 7
13
GND Input 3
GND Input 7
14
V Supply (5 V) Input 4
V Supply (5 V) Input 8
15
Not used
Not used
