150 Virtual Channels
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Data types:
Integer or Unsigned Integer
Integer or Unsigned Integer (2nd
parameter is an input channel)
Integer or Unsigned Integer
Integer or Unsigned Integer
Digital (2nd parameter is an input
channel)
Integer or Unsigned Integer
Integer or Unsigned Integer (2nd
parameter is an input channel)
Integer or Unsigned Integer
Digital (2nd parameter is an input
channel)
Integer or Unsigned Integer
2nd parameter is a numerical value
Integer or Unsigned Integer
2nd parameter is a numerical value
4.10.15 Button status (only for BRIGDE2 and UNI8 modules)
Clock pulse of result channel
Channel representing button status signal
Description: Outputs button status of BRIDGE2 or UNI8 module at specified sampling rate. If the button
was pressed the returned result is 1 for the duration of one pulse, else 0. When the button is pressed
only the signal edge is evaluated, i.e. it doesn't matter how long the button is held down. If the button
function is set to "Activate balance" or "Activate shunt calibration", the button only takes effect if
balancing (or shunt calibration) can be performed. During balancing or shunt calibration, the button
status is ignored.
Since it is the signal edge which counts, only a single 1 appears between sequences of zeroes.
Data types:
4.10.16 Channel-status word (only for UNI8 and CI8 modules)
Pulse rate of result channel
Current content of input channel's status word.
Description: A status word for channels of the universal amplifier module is outputted at the specified
clock pulse. In the basic state the status word's value is 0. Therefore channels 1 ... 8 are not balanced.
Depending on the status, the following values are added:
