IMC CANSAS - Μ-CAN - HUB4

µ-CAN - B1/B4 517
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
Parameter
Value
Remarks
Dimensions (W x H x D)
with / without terminal
connection
40 x 20 x 104 / 60 mm
40 x 20 x 114 / 70 mm
55 x 63 x 89 / 70 mm
µ-CANSAS-B1-AS
µ-CANSAS-B1-L
µ-CANSAS-B4-AS
Weight
0.08 kg
0.1 kg
0.26 kg
µ-CANSAS-B1-AS
µ-CANSAS-B1-L
µ-CANSAS-B4-AS
Terminal connection
Sensor
CAN, Supply
1x 8-pin Phoenix strip terminal (MPT0,5/8)
1x 37-pin Autosport Type: AS214-35SN
1x 6-pin Autosport Type: AS208-35PA
2x 5-pin LEMO: HGG.0B.305
1x 6-pin Autosport Type: AS208-35PA
1x 6-pin Autosport Type: AS208-35SA
µ-CANSAS-B1
µ-CANSAS-B4-AS
µ-CANSAS-B1-AS CAN OUT
µ-CANSAS-B1-L CAN IN and OUT
µ-CANSAS-B4-AS CAN IN
µ-CANSAS-B4-AS CAN OUT
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 1 PDO
only with µ-CANSAS-B1
in INT16, INT32, and FLOAT
TEDS - Transducer Electronic
DataSheets
conforming to IEEE 1451.4
Class II MMI
Module description µ-CANSAS-B1 and µ-CANSAS-B4 .
7.25 µ-CAN - HUB4
Technical Specs Version 1.3 (HUB for connecting up to four 1-channel µ-CANSAS modules)
Parameter
Value (min./ max.)
Remarks
Connections
4x 6-pin Autosport Type: AS208-35SA
2x 6-pin Autosport Type: AS208-35PA/SA
CAN (in) and power supply
for µ-CANSAS modules with
µ-CANSAS-HUB4-AS
CAN (in / out), power supply with
µ-CANSAS-HUB4-AS
Isolation
CAN-Bus, power supply
Analog inputs
60 V
60 V
to frame (CHASSIS)
nominal; tested at 500 V (10 s)
nominal; tested at 500 V (10 s)
Supply voltage
9 V to 50 V DC
Power consumption
1 W
module not connected
Operating temperature
-40°C to 120°C
Dimensions (B x H x T)
70 x 70 x 30 mm
without interconnections
Weight
200 g
Module description µ-CANSAS-HUB4
