7.29.4 DSUB connector for incremental sensors with current signals
Accessory: connector for incremental sensors with currents signals for use with an incremental encoder
interface
Parameter
typ.
min. / max.
Remarks
usable with
CRPL/ENC-4
CRPL/HRENC-4
C-Series/ENC-4
imc CANSAS/INC4
DSUB-15 connector
inputs
4 + 1
differential, non isolated
input coupling
DC
range
4 basic channels:
1 index channel:
±12 µA
±24 µA
sensitivity
4 basic channels:
1 index channel:
Vout = - 0.2 V / µA
Vout = - 0.1 V / µA
input impedance
4 basic channels:
1 index channel:
200 k
100 k
voltage output
differential
differential signal „+Vout“ – „-Vout“
analyzed by the INC-4 module
output level
approx. 0 V to 5 V
+Vout = 2.5 V - 0.2 V / µA
-Vout = 2.5 V
basic channels
analog bandwidth
4 basic channels:
1 index channel:
80 kHz
50 kHz
supply:
auxiliary power
5 V, 5 mA, 25 mW
supplied by the INC-4 module:
DSUB-15(14) VCC
connector plug
DSUB-15 with screw clamp in the
connector housing
