Function Reference 169
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
4.10.48 Output status on LED (only for BRIDGE2, UNI8 and CI8 modules)
BRIDGE2: Output status for
The channel whose status is to be represented by the LED.
Channel 1, Channel 2 or both
UNI8: Other or no sensors
The flashing pattern for the case that other or no sensors are connected
to the module.
See below for selection.
What flashing pattern indicates that the channel has not been balanced?
LED on
LED off
LED quick flashes
LED normal flashes
LED slow flashes
LED long flash on, short blink off
LED short blink on, long flash off
For "Stored balance values"
Sets flashing pattern for indicating that stored balance values used for
channel.
Selections see above.
For "Successfully balanced"
Sets flashing pattern for indicating that balance values used for channel.
Selections see above.
For "Balance in progress…"
Sets flashing pattern for indicating that balance is in progress.
Selections see above.
For "Shunt calibration in
progress"
Sets flashing pattern for indicating that shunt calibration in progress.
Selections see above.
Additional selection: "No LED-display"
Description:
BRIDGE2: Status information on the bridge amplifier module is outputted on the LED. The information
can reflect the status of either Channel 1, Channel 2, or both. If both channels are affected at once, the
status must be the same in both for the corresponding LED-display to be output. See the table below for
a list of the different states which can be represented:
For determining the status of both channels at once, the following must be noted: All status values
except "Successfully balanced" and "Not balanced" can only apply to both channels at once, anyway, so
they are the same for both channels. And if the channels have different status in terms of "balanced" or
"Not balanced", then "Not balanced" takes precedence.
Universal amplifier module:
