7.2 CANSER-GPS
Data Sheet Version 1.2 (CANSER GPS)
Parameter
Value
Remarks
Supply voltage
9 V to 32 V DC
Power consumption
<4 W
23°C
operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
Connection terminals
2x DSUB-9
2x DSUB-9
PHOENIX (MC 1,5/4STF-3,81)
outputs
CAN (in/out)
supply
Encoding of reception signals:
Message
ID
Byte
Remarks
Time
2020
0-3
Long
Date
2020
4-7
Long
Longitude
2021
0-3
Real; negative for Western Hemisphere
Latitude
2021
4-7
Real; negative for Southern Hemisphere
Velocity
2022
0-3
Real; unit: knots
Direction (course over ground)
2022
4-7
Real; direction in °
Elevation (above sea level)
2023
0-3
Real; in m
Satellite count
2023
4-5
Integer; number of satellites used
Status
2023
6-7
1: valid; 0: maintenance
Module description CANSER-GPS
