6.7 DCB8: bridge, strain gauges
This module provides eight differential, analog inputs with integrated sensor supply for the measurement
of resistive bridges or strain gauges, as well as voltage.
Technical Data DCB8.
The eight measurements inputs IN1 to IN8 whose terminals are 4 DSUB plugs are for voltage- and bridge
measurement. They are non-isolated differential amplifiers. They share a common voltage supply for
sensors and measurement bridges.
The DCB8 module is also available in the PROTECT model, having ESD and transients protection. See the
description of the UNI8 for properties and information on its constraints.
