6.16 P8 pressure
8 pressure measurement inputs
Parameter
Value (typ. / max)
Remarks
Inputs
8
Plus internal barometer for calculations
Measurement modes
pressure, absolute
pressure, relative
The imc CANSAS pressure module is offered in two housing varieties, imc CANSAS–L–P8, imc CANSAS-K-
P8 and imc CANSAS–IP65–P8, and can measure either absolute pressure or in relation to ambient
pressure. Technical data P8.
CANSAS-L-P8
CANSAS-P8-IP65
Figure 1:CANSAS-L-P8: preferred mounting position
Figure 2:CANSAS-IP65-P8: preferred mounting position
