7.8 DI16
Data Sheet Version 1.5 (16 digital inputs)
Parameter
Value
Remarks
Inputs
16
Common reference ground for each 2-
channel-group. Each 2-channel-group
isolated to other groups as well as to
power supply and CAN-bus.
Contacts
2x DSUB-15
Phoenix terminal block
16x ITT Veam
2x DSUB-9
PHOENIX (MC 1.5/4STF-3.81)
inputs CANSAS-DI16, -L- DI16
-K- DI16-DSUB
-K-DI16-Ph, -L-DI16-Ph
CANSAS-L-DI16-V
CAN (in / out), supply (alternatively)
supply
Contacts (SL)
2x DSUB-15 / 8 channels
2x 10-pin LEMO (HGA.1B.310)
1x 6-pin LEMO (HGA.1B.306)
inputs
CAN (in / out), supply (alternatively)
supply
Input voltage range
TTL or 24 V
software-configurable
Sampling rate
10 kHz
Input configuration
differential
isolated to power supply and channel-
to-channel
Input current
max. 500 µA
limited by current supply (min. current
100 µA)
Switching threshold
5 V operation (TTL)
24 V operation
V
L
max
= 0.8 V; V
H
min
= 2.0 V
V
L
max
= 5.0 V; V
H
min
= 8.0 V
typ. 1.7 V 200 mV
6.7 V 300 mV
CAN-Bus
defined as per ISO 11898
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 PDOs in
INT16, INT32, and FLOAT
Isolation:
CAN-Bus
power supply input
digital inputs
60 V
60 V
60 V
to case (CHASSIS)
nominal; testing: 300 V (10 s)
nominal; testing: 300 V (10 s)
nominal; testing: 300 V (10 s)
Overvoltage protection
60 V
differential input voltage
Supply voltage
10 V to 50 V DC
Power consumption
4 W (typ.)
12 V power supply, 23°C
Operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
35 x 111 x 145 mm
41 x 128 x 145 mm
41 x 128 x 145 mm
75 x 111 x 145 mm
152 x 111 x 145 mm
38 x 112.5 x 152 mm
CANSAS-DI16
CANSAS-L-DI16
CANSAS-K-DI16
CANSAS-K-DI16-DSUB
CANSAS-L-DI16-Ph
CANSAS-L-DI16-V
CANSAS-SL-DI16-D
Weight
300 g
