Data types:
Result channel
Integer
4.10.18 Comparison function
Parameter
Definition
Input channel
Channel whose sample values determine whether the samples from 'Output
channel' or the specified 'Result value' are adopted as return values of the function.
Output channel
Channel whose sample values are the function's return values if the Input channel's
corresponding value is TRUE (<> 0).
Result value
Number which is the function's return value whenever the Input channel's value is
FALSE (= 0).
Result channel
Channel containing the results of the decision function.
Description: If the current value of the digital input channel does not equal zero, the result is the value of
the output channel, otherwise it is the stated return value.
Notes: Input channel and Output channel must share the same sampling rate. Result value must be
specified in the physical units of Output channel.
Data types:
Input channel
Result channel
Integer or Digital
Integer
4.10.19 Constant channel (only for acquisition modules)
Parameter
Definition
Input channel
Channel whose values are to be set to a constant value
Value
Specified numerical value
Result channel
Constant-value channel.
Description: Any given value from the input channel is replaced with the specified, constant value.
Notes: The constant value is specified in the physical units of the input channel. The input channel's
scaling remains intact.
Data types:
Input channel
Result channel
Integer or Digital
Integer
