7.10 DO8R, DO16R
Data Sheet Version 1.7 (8 or 16 relay outputs)
Parameter
Value (typ./max.)
Remarks
Relays
8
16
DO8R
DO16R
Relay specs:
Switching current
Switching power
Switching voltage
Switching time
1 A @ 30 V DC (max.)
10 µA @ 10 mV DC (min.)
0.3 A @ 125 V AC (max.)
30 W (max.)
37.5 W (max.)
110 V DC
125 V AC
< 8 ms
Power-up default
all deactivated
CAN-Bus
defined by ISO 11898
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 1 RPDO in
INT16, INT32, and FLOAT
only with DO8R
Isolation:
CAN-Bus
power supply input
60 V
60 V
to CHASSIS
nominal; testing: 300 V(10 s)
nominal; testing: 300 V(10 s)
Supply voltage
10 V to 50 V DC
Power consumption
4 W (typ.)
12 V supply, 23 °C
operating temperature
-30°C to 85°C
Dimensions (W x H x D)
35 x 111 x 90 mm
35 x 111 x 145 mm
75 x 111 x 145 mm
81 x 128 x 145 mm
75 x 111 x 145 mm
CANSAS-DO8R
CANSAS-L-DO16R
CANSAS-L-DO8R-Ph
CANSAS-K-DO16R (8TE)
CANSAS-L-DO8R-V
Weight
300 g
Connection terminals
2x DSUB-15
4x DSUB-15
8x ITT VEAM
PHOENIX terminal block
2x DSUB-9
PHOENIX (MC 1,5/4STF-3,81)
outputs : DO8R
-L-DO16R
-L-DO8R-V
-L-DO8R-Ph, K-DO16R
CAN (in/out)
supply
Module description DO8R, DO16R
