7.21 UNI8
Data Sheet Version 1.6
Parameter
Value
Remarks
Inputs
8
differential, separate inputs
Measurement modes
DSUB
voltage measurement
voltage measurement with
adjusted supply
current measurement
thermocouples (mounted with and
without contact to GND)
resistor
Pt100 in 3- and 4-wire configuration
bridge-sensor
bridge: strain gauge
internal shunt (single-end) or with shunt
connector (ACC/DSUB(M)-I2)
Measurement modes
LEMO and ITT Veam
voltage measurement
voltage measurement with
adjusted supply
current measurement
thermocouples (mounted with and
without contact to GND)
resistor
Pt100 in 3- and 4-wire configuration
bridge-sensor
bridge: strain gauge
internal shunt (single-end)
LEMO connector with built-in cold-
junction compensation (CJC)
ACC/TH-LEM-150
Sampling rate, Bandwidth, CANopen®, TEDS
Parameter
Value
Remarks
Sampling rate
1 kHz
per channel
Bandwidth
0 Hz to 200 Hz
-3 dB; Filter OFF
0 Hz to 190 Hz
-3 dB; with AAF-filter
Resolution
16 bit
internal 24 bit processing
CANopen mode
"CiA DS 301 V4.0.2" and
"CiA DS 404V1.2"
supports 4 PDOs in
INT16, INT32, and FLOAT
TEDS - Transducer
Electronic Data Sheets
conform IEEE 1451.4
Class II MMI
ACC/DSUB(M)-TEDS-xxx
