SENT-input configuration options
Parameter
Value typ.
min. / max.
Remarks
Serial protocol
without
short
enhanced (12 bit)
enhanced (16 bit)
Clock Tick length
3 to 90 s
resolution in steps of 0.1 s
Number of data nibbles
1 to 6
Pause Pulse Option
npp: no pause pulse
pp: pause pulse
ppc: pause pulse with constant frame length
Pause pulse frame length
147 to 922 Ticks
expressed in clock ticks
CRC
is verified
Reduction
1 to 100
A number of FAST channel
samples will create and output
one single CAN message.
Number of FAST-channels
1 to 4
per SENT-inputs
Nibble order
MSN first
LSN first
set separately for each FAST-
channel
Start bit position
0 to 23
set separately for each FAST-
channel
Number of bits
1 to 16
set separately for each FAST-
channel
Data type
signed integer
unsigned integer
set separately for each FAST-
channel
Scaling
linear scaling possible
Status-Channel
4+4+1 bit
CRC, communication-nibble, CRC-
Valid bit
Passive monitoring
yes / no
Parameterized separately for each
input; tapped without power
supply or feedback
CAN-message rate
5000 / s
fully compatible
Module description: SENT
Included accessory
Getting Started
Terminal connector for supply voltage via Phoenix plug
Additional options and accessories
The modules can be configured for CAN-network applications either -by order- at factory, or by the
customer using appropriate configuration software. The necessary software as well as cables and
additional accessories are presented in the documentation "Integrating CANSAS in CAN Networks".
