7.24 µ-CAN - B1/B4
Data Sheet Version 1.5
Parameter
Value
Remarks
Channels
1
4
µ-CANSAS-B1
µ-CANSAS-B4
Measurement modes
full bridge, half bridge
unbalance: max 70%
input: +IN_1V, -IN_COM
Sampling rate / channel
2 kHz
Analog bandwidth
840 Hz
-3 dB
AD-conversion
24 bit
Input ranges
200 mV/V, 100 mV/V, 50 mV/V,
20 mV/V, 10 mV/V, 5 mV/V,
2 mV/V, 1 mV/V, 0.5 mV/V
Bridge supply
5 V
DC; max 210 mW, short-circuit
protection 1 s
Isolation
60 V / 500 V
long-term / 10 s
Max. sustainable voltage
40 V / 100 V
long-term / 1 s
Min. bridge impedance
120
I
max
=42 mA
Input impedance
5 M
10 k
Input: +IN
Input: +IN for voltage surge,
or deactivated
Gain uncertainty
<0.1 %
of measured value
Offset of input range
<0.02 %
<2 µV/V
200 mV/V to 10 mV/V
< 10 mV/V
Offset drift
0.04 V/V/K
Noise
0.32 V
rms
full bridge, dR/R=0
IMR
0.004 µV/V / V
50 Hz
Supply voltage
9 V to 50 V DC
Power consumption
typ. 1 W, max. 1.5 W
typ. 4 W, max. 4.5 W
µ-CANSAS-B1
µ-CANSAS-B4
Temperature range
-40°C to 120°C
operating temperature
