IMC CANSAS - Cansas-L-Di16-Ph

Signal connection 555
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
8.3.7.3 CANSAS-L-DI16-PH
Signal
left terminal block
right terminal block
Signal
1+
+IN 1
+IN 9
9+
1-
-IN 1
-IN 9
9-
2+
+IN 2
+IN 10
10+
2-
-IN 2
-IN 10
10-
3+
+IN 3
+IN 11
11+
3-
-IN 3
-IN 11
11-
4+
+IN 4
+IN 12
12+
4-
-IN 4
-IN 12
12-
5+
+IN 5
+IN 13
13+
5-
-IN 5
-IN 13
13-
6+
+IN 6
+IN 14
14+
6-
-IN 6
-IN 14
14-
7+
+IN 7
+IN 15
15+
7-
-IN 7
-IN 15
15-
8+
+IN 8
+IN 16
16+
8-
-IN 8
-IN 16
16-
Supply *
5 VDC
5 VDC
Supply *
Supply *
5 VDC
5 VDC
Supply *
Ground *
GND
GND
Ground *
CHASSIS
CHASSIS
CHASSIS
CHASSIS
* updated pin configuration, starting from July 2011
