6.17.2 Scaling
The scaling of the duty cycle ratio has to be entered on the Message Mapping card:
Per default the physical quantity of input is set to 0-10 V. To use the possible integer range of 2^16, a
value between 0 and 65535 is expected. A factor of 1,525902e-4 multiplies a result to a maximum of 10
V.
Alternative a factor of 1 causes a range of 0 to 65535 (V) :
