7.29 Accessories
7.29.1 DSUB-screw terminals for measurement inputs
All plugs are 15-pin connection blocks made for direct connection to the imc CANSAS sockets CON1 and
CON2. For attaching the lines, there are screw terminals inside the plug enclosure.
Measurement
Comments
Order-#
Voltage
voltage measurement with 4 differential channels.
ACC/DSUB-U4
CAN/DSUB-U4 for ISO8
voltage measurement with imc CANSAS-C12 (without divider)
for 6 differential channels
CAN/DSUB-U6 for C12
Voltage with
divider
voltage measurement with imc CANSAS-C12 with 1:100
Dividers for 6 differential channels, for connection of voltages
up to 50V
CAN/DSUB-U6D for C12
voltage measurement with imc CANSAS-ISO8 with 1:100
divider for 4 differential channels, for connection of voltages
up to 50V
ACC/DSUB-U4
CAN/DSUB-U4D for ISO8
Current
current measurement (0..40 mA) with imc CANSAS-C12
with 50 (0,1%) shunt equipped with 6 differential channels
CAN/DSUB-I6 for C12
current measurement (0..40 mA) with 50 (0,1%) shunt
equipped for 4 differential channels
ACC/DSUB-I4
CAN/DSUB-I4 for ISO8
current measurement with 50 (0,1%) shunt equipped for 2
differential channels
ACC/DSUB-UNI8-I
Thermocouples
direct connection of 6 thermocouples to imc CANSAS-C12. In
the terminal connector, an isothermal plate and a Pt100 for
cold junction compensation are built in
CAN/DSUB-T6 for C12
direct connection of 4 thermocouples. In the terminal
connector, an isothermal plate and a Pt100 for cold junction
compensation are built in.
ACC/DSUB-T4
CAN/DSUB-T4 for ISO8
Pt100
connection of 4 Pt100 measurement resistors
CAN/DSUB-Pt100 for C12 and
ISO8
ACC/DSUB-T4
Measurement
bridges
bridge measurement for two channels with imc CANSAS-
BRIDGE2
ACC/DSUB-B1
bridge measurement for two channels with imc CANSAS-UNI8
ACC/DSUB-B2
Incremental
encoder inputs
connection of 4 incremental encoders imc CANSAS-INC4
connection of 4 incremental encoders with current signal
ACC /DSUB-ENC4
ACC/DSUB-ENC4-IU
Analog outputs
4 analog output channels for imc CANSAS-DAC8
ACC /DSUB-DAC4
Digital inputs
8 digital inputs for connection to imc CANSAS-DI16
CAN/DSUB-DI
Digital outputs
8 digital outputs for connection to imc CANSAS-DO16
ACC /DSUB-DO8
Relay outputs
four relays for connection to imc CANSAS-DO8R
ACC /DSUB-REL4
Voltage, current,
bridge, resistor,
temperature
all-purpose connector for two channels to imc CANSAS-UNI8:
voltage, current, resistance, bridge, thermocouples, Pt100
ACC/DSUB-UNI8-UNI
PWM8
4 digital outputs for connection to imc CANSAS-PWM8
ACC/DSUB-PWM4
