Function Reference 167
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
4.10.45 Minimum
Channel whose minima within each reduction interval are to be determined
Data rate of result channel
Channel containing the minima of the input channel within the data
reduction interval.
Description: The minimum values within each reduction interval in the channel are determined. The
reduction interval is the clock pulse of the result channel. The values returned are a sequence of the
minima found.
Notes: The result clock pulse may not exceed the input channel's sampling rate.
Data types:
4.10.46 Module-status word (only for UNI8 and CI8 modules)
Sampling rate of result channel
Current content of result channel's status word
Description: Status word for universal amplifier module is outputted at the specified clock rate. In the
basic state, the status word takes the value 0.
Depending on the status, the following values are added:
+1, if system is in the process of adjusting/balancing
+2, if system is in the process of performing shunt calibration
+4, if the module button is pressed (edge detection)
+8, if short circuit
+16, if the module is running in synchronized mode
Remark: If the function of the module button is set to "Activate balance " or "Shunt calibration", the
system only takes not of the button if it is possible to perform calibration or adjustment/balancing.
During balancing or shunt calibration, the button status is not regarded.
It is possible to run multiple CANSAS-modules in synchronicity to each other, to the DCF-signal or to
MUSYCS. For synchronized operation, the corresponding status value is added.
Data types:
