IMC CANSAS - Modules with ITT VEAM Terminals

Signal connection 551
imc CANSAS Users Manual - Doc. Version 1.9 - 05.12.2014© 2014 imc Meßsysteme GmbH
8.3.5 Modules with ITT VEAM terminals
CAN/L-UNI8
CAN/L-CI8-V
CAN/L-CI8-V-SUPPLY
1050051
1050293
1050364
Round plugs ITT-VEAM (MIL-C-26482)
ITT VEAM
PIN
-UNI8
-L-CI8-V-(SUPPLY*)
A
+IN
+IN
B
-IN
-IN
C
+SUPPLY
(+SUPPLY)
D
-SUPPLY
GND (-SUPPLY)
E
TEDS
TEDS (OneWire)
F
SENSE/
RTD current source
I_PT (RTD
current source)
G
quarter bridge completion, Sense-lead
for RTD 3-wire connector
+I
(positiver Messeingang für Strommessung)
* - Sensor supply voltages available with optional sensor supply module
imc CANSAS -L-DO8R-V, -L-DI16-V, -L-DAC8-V, -L-PWM8-V
ITT VEAM
PIN
-L-DO8R-V
-L-DI16-V
-L-DAC8-V
L-PWM8-V
A
IN
+IN
PWM Open Drain
B
ON
-IN
C
OFF
OUT
Vcc
D
GND
GND
E
F
PWM TTL
G
CHASSIS
CHASSIS
CHASSIS
CHASSIS
